M30
Dimensions: 45mm * 45mm
Quad-Core ARM Cortex-A35
Mali-G31 GPU, support OpenGL ES3.2, Vulkan 1.0, OpenCL 2.0
RGB/LVDS/MIPI-DSI, with a maximum resolution of 1920×1080
Dual screen display
This is the first cost-effective 64 bit quad core A35 application processor for industrial applications. With long life cycle and high cost performance, it can meet the needs of most industries.
Feature
-
PX30 quad-core 64-bit processor
Low power consumption and strong compatibility
Quad core cortex-a35 low power and high performance processor -
Integrated co-processors — GPU, VPU
The GPU supports OpenGL ES3.2, Vulkan 1.0, OpenCL 2.0，with a high-performance dedicated 2D processor. The VPU supports multi-format 1080P@60fps video decoders (H.265, H.264,VC-1, MPEG-1/2/4, VP8), 1080P(H.264,VP8) video encoding.
-
Various display interfaces
Support RGB/LVDS/MIPI-DSI interface, LVDS interface supports 1280×800@60fps, RGB / MIPI-DSI interface supports 1080P@60fps, supports dual VOP (dual screen display).
-
Long stable operation
The M30 core board leads to all the pins of the chip, and the performance of data transmission and expansion is maximized. The pins of the immersion gold process are corrosion-resistant, firm and reliable, and can work at the temperature of -20℃-80℃, stable operation for 7×24 hours.
Specifications
| Parameters | |
|---|---|
| Chip |
|
| CPU |
Quad-Core ARM® Cortex-A35 processor |
| GPU |
Mali-G31GPU, Support OpenGL ES3.2, Vulkan 1.0, OpenCL 2.0 Built-in embedded high-performance 2D acceleration hardware |
| VPU |
Multi-format1080P@60fps (H.265,H.264,VC-1, MPEG-1/2/4, VP8) video decoding Support 1080P (H.264,VP8) video encoding |
| RAM |
DDR3 (1GB/2GB) （Optional） |
| Storage |
eMMC 5.1 (8GB/16GB/32GB/64GB/128GB) （Optional） |
| Hardware Features | |
|---|---|
| Ethernet |
Support 100M Ethernet interface |
| WiFi&BT |
WiFi&BT interface, can expand WiFi&Bluetooth function |
| Display |
Support RGB/LVDS/MIPI-DSI interface Support VOP (dual screen simultaneous display), resolution up to 1920×1080 |
| Audio |
1 x SPDIF Digital audio interface for audio output 1 x 8ch I²S /TDM 1 x 8ch PDM 1 x 2ch I²S/PCM |
| USB |
1 x OTG 1 x USB2.0 HOST |
| IR |
Support infrared remote control function |
| Webcam |
1 × MIPI CSI camera interface 1 × DVP camera interface |
| Extension ports |
Build-in I2C、UART、SPI、SDIO3.0、USB2.0、PWM、RMII、 I2S (Support 8-channel digital microphone array input) |
| OS/Software | |
|---|---|
| OS |
Android/Linux |
| Others | |
|---|---|
| Size diagram |
|
| Size |
45mm*45mm |
| Pitch |
1.2mm |
| Number of pins |
144PIN |
| Power Supply |
5V / 1A |
| Operating temperature |
-10℃-60℃ |
| Storage temperature |
-10℃-60℃ |
| Storage Humidity |
10%-80% |
| PCB specification |
4-layer board design |
| Application | |
|---|---|
| Multiple -function |
|
| Data sheet | |
|---|---|
|
|
|
